Description

Standard hydraulic unit for 6″ vises
Can be single or double acting
Complete unit with spring, washers, bearing pack, & fittings

Resources

• Removal and Installation Instructions  (vnd.openxmlformats-officedocument.wordprocessingml.document)

Dimensional Data

• Stroke: 0.25 in.
• Piston area: 2.74 sq. in.
• Hydraulic displacement: 0.69 cu. in.
• Operating Pressure: 3200 psi
• Theoretical clamp force at 3200 psi: 8768 lbs.
• Expected clamp force approximately 7365 lbs.
• Pressure/return ports: 1/8 in. npt
